so this is exciting! Umfeld can run on a Raspberry Pi 4 Model B or Raspberry Pi 5.

next stop: get Kernel Mode Setting with Direct Rendering Manager (KMSDRM) up and runnning! i have already compiled and ran a minimal demo with ImGui … nice!

the following step-by-step guid is also published and will be updated in the repository at Umfeld on Raspberry Pi:

Umfeld on Raspberry Pi

RPI currently uses X11 as the rendering system when in desktop environment. however, there is also an allegedly much faster KMS ( or KMSDRM ) rendering system which can start fullscreen windows without(!) a GUI i.e from the command-line ( and even from a remote machine via SSH ). i have tested this already, it does work but requires some extra development. stay tuned.

Umfeld was tested on Raspberry Pi 4 Model B with Raspberry Pi OS (64-bit), Debian Bookworm ( Released: 2024-11-19 ).

however, it has not been tested carefully. there might be glitches …

PS RPI does not support antialiasing i.e make sure to set the value to 0 in settings:

void settings(){
    antialiasing = 0;
}

this step by step guide has been tested on a Raspberry Pi 4 Model B with Raspberry Pi OS (64-bit), Debian Bookworm ( Released: 2024-11-19 ) installed.

Quick Start

for a quick start an image with Umfeld and all dependencies can be download from: http://dm-hb.de/umfeld-rpi

the image has been tested on Raspberry Pi 4 Model B with Raspberry Pi OS (64-bit), Debian Bookworm ( Released: 2024-11-19 ).

the credentials are:

  • name ……. : umfeld.local
  • user ……. : umfeld
  • password … : umfeld123

Preparing the Build Environment

install all packages:

sudo apt-get update -y
sudo apt-get upgrade -y
sudo apt-get install cmake libglew-dev libharfbuzz-dev libfreetype6-dev ffmpeg libavcodec-dev libavformat-dev libavutil-dev libswscale-dev libavdevice-dev librtmidi-dev libglm-dev portaudio19-dev -y
#sudo apt-get install libsdl3-dev # currently (2025-04-01) not available

note, the following packagae are also required but come pre-installed with the OS distribution:

  • gcc (v12.2.0)
  • git (v2.39.5)
  • pkg-config (v1.8.1)

since SDL3 is currently not available via apt ( i.e apt-get install libsdl3-dev ) we need to build SDL3 from source and install it.

Build SDL3 from Source

sudo apt-get update -y ; sudo apt-get upgrade -y
sudo apt-get install cmake
git clone https://github.com/libsdl-org/SDL.git
cd SDL
# cmake -S . -B build -DSDL_ALSA=ON -DSDL_PULSEAUDIO=ON -DSDL_PIPEWIRE=ON -DSDL_JACK=ON -DCMAKE_BUILD_TYPE=Release
# cmake -S . -B build -DVIDEO_KMSDRM=ON -DVIDEO_X11=ON -DVIDEO_WAYLAND=ON -DRENDER_OPENGL=ON -DRENDER_OPENGLES=ON -DCMAKE_BUILD_TYPE=Release
cmake -S . -B build -DVIDEO_KMSDRM=ON -DVIDEO_X11=ON -DVIDEO_WAYLAND=ON -DRENDER_OPENGL=ON -DRENDER_OPENGLES=ON -DSDL_ALSA=ON -DSDL_PULSEAUDIO=ON -DSDL_PIPEWIRE=ON -DSDL_JACK=ON -DCMAKE_BUILD_TYPE=Release ## TODO check if all build flags are correct and needed
cmake --build build # `--parallel` is optional for building with multiple cores but currently kills the RPI
sudo cmake --install build --prefix /usr/local

now SDL3 is properly installed and can be used for build ( i.e pkg-config --libs --cflags sdl3 provides all compile flags ).

Setting up Umfeld

first clone umfeld and the umfeld-examples repositories with submodules from GitHub:

git clone --recurse-submodules https://codeberg.org/Umfeld/umfeld.git
git clone --recurse-submodules https://codeberg.org/Umfeld/umfeld-examples.git

now enter the example directory, to build and run an example e.g a basic minimal example:

cd umfeld-examples/Basics/minimal
cmake -B build
cmake --build build # --parallel
./build/minimal

note, the first time might take a bit on a small machine. note, examples can not be run from ssh sessions ( without X11 forwarding ).

X11 Forwarding

to run GUI applications from another machine via ssh the following steps must be taken:

  • check that remote RPI has X11 forwarding enabled. in /etc/ssh/sshd_config confirm that X11Forwarding yes. if not change it an restart ssh with sudo systemctl restart ssh
  • make sure local machine has an X server running ( e.g for macOS install XQuartz with brew install xquartz )
  • start ssh session from local machine with -Y option e.g ssh -Y umfeld@umfeld.local
  • run application with DISPLAY set to remote screen e.g DISPLAY=:0 ./umgegbung-application
